AOD452A – N

The AOD452A is fabricated with SDMOSTM trench technology that combines excellent RDS(ON) with a low gate charge. The result is outstanding efficiency with controlled switching behavior. This universal technology is well suited for PWM, load switching, and general-purpose applications.

Features/Specs:

• Part No: AOD452A
• Manufacturer: Generic
• FET Type: N-Channel
• Drain to Source Voltage (Vdss): 25 V
• Current – Continuous Drain (Id) @ 25°C: 55A (Tc)
• Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
• Rds On (Max) @ Id, Vgs: 8mOhm @ 30A, 10V
• Vgs(th) (Max) @ Id: 3V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs: 26 nC @ 10 V
• Vgs (Max): ±20V
• Input Capacitance (Ciss) (Max) @ Vds: 1450 pF @ 12.5 V
• Power Dissipation (Max): 2.5W (Ta), 50W (Tc)
• Operating Temperature: -55°C ~ 175°C (TJ)
• Package / Case: TO-252-3
